Manufacturing capabilities
Wire conveyor belts made to specification at our works in Maharashtra and Uttarakhand.
Capabilities at a glance
All belts are made to order. The ranges below are from our published specifications.
| Area | Capability |
|---|---|
| Weaves | Z-47 articulated, balanced, compound balanced, rod reinforced, closed pitch (CB-5), Gratex, laminated (eye-link), honeycomb, enrober, flat wire, chain driven |
| Edges | Welded, bent, chain edge (bolted or welded) |
| Materials | Mild steel; stainless AISI 304, 316, 316L, 321, 310, 310S, 430; Inconel 600; nickel-chrome |
| Wire diameters (published ranges) | 0.71 mm to 4.02 mm (mesh belts); 0.90–1.40 mm (Z-47); 2–3.5 mm eye-link (laminated) |
| Widths | Laminated belts 100 mm to 6000 mm; other belts made to requirement |
| Temperature | −40 °C (laminated, freezing) to 1150 °C (Inconel 600 / nickel-chrome) |
| Works | Ambernath – 421501 (Maharashtra); Rudrapur (Uttarakhand) |
| Certification | ISO 9001:2015 quality management system; MSME ZED Silver |
How an order moves through our works
Requirement review
We study your conveyor, product, load and temperature — from your form, drawing or a sample of your old belt.
Material selection
We select the alloy and wire for the duty, using quality wire from Tata Steel and Visakhapatnam Steel.
Weaving & forming
Spirals, rods, links or strips are formed and assembled into the chosen weave — balanced, rod reinforced, Z-47, laminated and more.
Edge finishing
Edges are welded, bent or fitted with side chains to suit the conveyor.
Inspection
Every belt is factory-inspected for accurate specification and workmanship.
Dispatch & support
Belts are dispatched across India and for export, with technical support for installation.
ISO 9001:2015 & MSME ZED Silver certified
Our quality management system is certified to ISO 9001:2015, and we hold a ZED (Zero Defect Zero Effect) Silver certification under the Ministry of Micro, Small & Medium Enterprises, Government of India.
Looking for a conveyor belt built for your application?
Send us your belt width, length, material and process details — or a drawing or photo of your current belt — and our engineers will recommend a specification and quote.
